Microsampling

Home Microsampling Page 1 of 2

Filter by:

Sort by:

Advanced precision microsampling for COVID-19 research

Advanced precision microsampling for COVID-19 research

Brochure - hemaPEN

Brochure - hemaPEN

Brochure - hemaPEN (research use only)

Brochure - hemaPEN (research use only)

BR-0490-G_RevE_JP_cover

Brochure - hemaPEN (research use only) (Japanese)

Brochure - Sample collection

Brochure - Sample collection

Brochure - SARS-CoV-2 serology testing

Brochure - SARS-CoV-2 serology testing

hemaPEN

Contact us for more information or to request a quote

Advanced precision microsampling

hemaPEN provides a convenient sampling procedure for collection and storage of four dried blood spot (DBS) samples to drive information-rich decision making.

Unlike conventional DBS sampling tools, hemaPEN enables collection of an accurate and precise fixed micro-volume, and is designed to maintain sample integrity for quantitative analysis.

An easy-to-use sophisticated microsampling tool in the hands of non-analysts.

Features and benefits

Pen-like design for intuitive use.
Ability to collect blood from any source.
Capillary-based technology enables autonomous accurate fixed volume collection.
Four replicate samples from a single source.
Eliminates analytically relevant hematocrit bias.
Single-use and tamper-resistant.
Contained sample to minimize contamination.
Consistent sample drying profile.
Dried format for simplified storage and logistics.
Samples integrated directly into analytical workflow.
Sample cartridge compatible with standard 96-/24-well plates.
2D barcode and individual device serial number for traceability and chain of custody.
Space available for customized laboratory labelling.

Recommended applications

Quantitative analysis
Small volume sampling
Frequent sampling
Remote sampling
Blood sampling

Product specifications

hemaPEN functionality remains consistent independent of substrate. Each hemaPEN is identified through a specific model number which references substrate material, volume of capillaries and hemaPEN model type.

Substrate	Volume reference	Model	Model number
D* = 226™	300 = 2.74 μL	S = Standard (base model)	D300S
W† = 903^®	300 = 2.74 μL	S = Standard (base model)	W300S

Technical data

Product features
Sample type	Whole blood
Storage format	Dried
Sample volumetric accuracy	2.74 μL ±5% (0.14 μL)
Volumetric precision	CV <2.5% (interdevice)
Number of samples collected	4
Capillary specification	K2 EDTA-coated borosilicate Type 1 USP
Substrate dimensions	3.5 mm diameter
Substrate	226™ or 903^®
Shelf life	One year
Material and colors
Product color	White main body, a clear plastic tip and base and a green indicator stripe
Packaging
Units/pack	Provided as a single unit per pack
Pack dimensions	160 mm x 230 mm x 50 mm

*226™ supplied by PerkinElmer Pty Ltd. 226™ is a trademark of PerkinElmer, Inc or its affiliated entities. †903^® 100% cotton fiber supplied by Eastern Business Forms, Inc. 903^® is a registered trademark of Eastern Business Forms, Inc.

More

More information about hemaPEN

hemaPEN^® is supplied for therapeutic or IVD use in Australia, New Zealand, UK, EU and USA only: ARTG number: 280007; CE mark, general IVD; US FDA number: D410490. Outside of the territories listed above, the hemaPEN is supplied for research purposes only and not for therapeutic or diagnostic use.

View full product details

hemaPEN (research use only)

hemaPEN (research use only)

This information is relevant for hemaPEN supplied for research purposes only. This device is not for therapeutic or diagnostic use.

For information about hemaPEN supplied for therapeutic or IVD use, please click here.

Contact us for more information or to request a quote

Advanced precision microsampling

hemaPEN provides a convenient sampling procedure for collection and storage of four dried blood spot (DBS) samples to drive information-rich decision making.

Unlike conventional DBS sampling tools, hemaPEN enables collection of an accurate and precise fixed micro-volume, and is designed to maintain sample integrity for quantitative analysis.

An easy-to-use sophisticated microsampling tool in the handsof non-analysts.

Features and benefits

Pen-like design for intuitive use.
Ability to collect blood from any source.
Capillary-based technology enables autonomous accurate fixed volume collection.
Four replicate samples from a single source.
Eliminates analytically relevant hematocrit bias.
Single-use and tamper-resistant.
Contained sample to minimize contamination.
Consistent sample drying profile.
Dried format for simplified storage and logistics.
Samples integrated directly into analytical workflow.
Sample cartridge compatible with standard 96-/24-well plates.
2D barcode and individual device serial number for traceability and chain of custody.
Space available for customized laboratory labelling.

Recommended applications

Quantitative analysis
Small volume sampling
Frequent sampling
Remote sampling
Blood sampling

Product specifications

hemaPEN functionality remains consistent independent of substrate. Each hemaPEN is identified through a specific model number which references substrate material, volume of capillaries and hemaPEN model type.

Substrate	Volume reference	Model	Model number
D* = 226™	300 = 2.74 μL	S = Standard (base model)	D300S
W† = 903^®	300 = 2.74 μL	S = Standard (base model)	W300S

Technical data

Product features
Sample type	Whole blood
Storage format	Dried
Sample volumetric accuracy	2.74 μL ±5% (0.14 μL)
Volumetric precision	CV <2.5% (interdevice)
Number of samples collected	4
Capillary specification	K2 EDTA-coated borosilicate Type 1 USP
Substrate dimensions	3.5 mm diameter
Substrate	226™ or 903^®
Shelf life	One year
Material and colors
Product color	White main body, a clear plastic tip and base and a green indicator stripe
Packaging
Units/pack	Provided as a single unit per pack
Pack dimensions	160 mm x 230 mm x 50 mm

*226™ supplied by PerkinElmer Pty Ltd. 226™ is a trademark of PerkinElmer, Inc or its affiliated entities. †903^® 100% cotton fiber supplied by Eastern Business Forms, Inc. 903^® is a registered trademark of Eastern Business Forms, Inc.

More

More information about hemaPEN (research use only)

View full product details

Instructions for use - hemaPEN

Instructions for use - hemaPEN

Instructions for use - hemaPEN (research use only)

Instructions for use - hemaPEN (research use only)

Instructions for use - hemaPEN opening tool

Instructions for use - hemaPEN opening tool

Part Number List - hemaPEN

Part Number List - hemaPEN

Part Number List - hemaPEN

Download: Part Number List - hemaPEN [PDF]

Also see: Product Data Sheet - hemaPEN

Find in table:

Part number	Part description and detail
498100000	hemaPEN D300S
498100010	hemaPEN W300S

hemaPEN^® is supplied for therapeutic or IVD use in Australia, New Zealand, UK, EU and USA only: ARTG number: 280007; CE mark, general IVD; US FDA number: D410490. Outside of the territories listed above, the hemaPEN is supplied for research purposes only and not for therapeutic or diagnostic use.

View full product details

PDPN-1150-G_RevB_cover

Part Number List - hemaPEN (research use only)

Part Number List - hemaPEN (research use only)

Download: Part Number List - hemaPEN (research use only) [PDF]

Also see: Product Data Sheet - hemaPEN (research use only)

Find in table:

Part number	Part description and detail
498100001	hemaPEN D300S RUO
498100011	hemaPEN W300S RUO

hemaPEN^® is supplied for therapeutic or IVD use in Australia, New Zealand, UK, EU and USA only: ARTG number: 280007; CE mark, general IVD; US FDA number: D410490. Outside of the territories listed above, the hemaPEN is supplied for research purposes only and not for therapeutic or diagnostic use.

View full product details

Poster - Blood sampling made easy

Poster - Blood sampling made easy

Product Data Sheet - hemaPEN

Product Data Sheet - hemaPEN

Product Data Sheet - hemaPEN (research use only)

Product Data Sheet - hemaPEN (research use only)

Product Specification Sheet - hemaPEN

Product Specification Sheet - hemaPEN

PSS-0008-G_RevC_cover

Product Specification Sheet - hemaPEN (research use only)

Quick guide - hemaPEN

Quick guide - hemaPEN

Quick guide - hemaPEN (research use only)

Quick guide - hemaPEN (research use only)

Quick guide translations - hemaPEN

Quick guide translations - hemaPEN

Technical Poster - Collection and storage of volumetrically accurate and precise dried blood spots in a contained device: hemaPEN

Technical Poster - Collection and storage of volumetrically accurate and precise dried blood spots in a contained device: hemaPEN

Technical Poster - Improved dried blood spot-based metabolomics using a novel microsampling device

Technical Poster - Improved dried blood spot-based metabolomics using a novel microsampling device

Technical Poster - Incorporating novel synthetic DBS substrates into a blood microsampling device for multi-omics analyses

Technical Poster - Incorporating novel synthetic DBS substrates into a blood microsampling device for multi-omics analyses

1 2 Next »
