Turn imagination into results
High quality phases and a variety of hardware options provide a perfect match for all your separation needs.
Features and benefits
- Pore sizes to suit your analysis (1000 Å or 120 Å).
- Intermediate polarity C8 phase.
- Continuity of using HPLC for all separation needs simplifies your workflow.
- Facilitates the use of MS.
- Eliminate SDS-PAGE from your workflow.
Recommended applications
120 Å recommended for compounds too strongly retained on C18 phases, 1000 Å recommended for proteins.
Product specifications
0.15, 0.3, 1, 2.1, 3, and 4.6 mm ID columns available in 50, 100, 150, 250 mm lengths.
PEEK coated, and PEEKsil®, column hardware available to reduce non-specific interactions when analyzing compounds with metal chelating activity.
Phase |
Pore size (Å) |
Particle size (µm) |
Pore volume (mL) |
Surface area |
Carbon load % |
USP Code |
C8 |
120 |
5 |
1.0 ± 0.1 |
300 ± 40 |
11.7 |
L7 |
C8 |
1000 |
3 |
0.8 ± 0.1 |
25 ± 5 |
0.7 |
L7 |
More
Please refer to the part number list for more items.
9 products
![Image representing C8 ProteCol HPLC Capillary Columns](http://www.trajanscimed.com/cdn/shop/products/hplc_capillary_columns_hplc_capillary_column_protecol_dark_blue_sge_image_8017e4fc-c2a2-4a0e-9a52-1782d2412570.jpg?v=1571276982&width=1024)
C8H x 3 µm Particle Size x 1000 Å Pore Size, 100 mm Length x 150 µm ID, PEEKsil ProteCol HPLC Capillary Column
Collections: All, Analytical, C8 ProteCol HPLC columns, ProteCol HPLC capillary columns, Select by instrument - Analytical
![Image representing C8 ProteCol HPLC Columns](http://www.trajanscimed.com/cdn/shop/products/hplc_columns_reverse_phase_hplc_column_protecol_c18_red_sge_image_44a967fd-ba3e-4eb6-92f4-83cec08c5878.jpg?v=1571276982&width=1024)
C8H x 3 µm Particle Size x 1000 Å Pore Size, 100 mm Length x 2.1 mm ID, PEEK Coated ProteCol HPLC Column
Collections: All, Analytical, C8 ProteCol HPLC columns, Select by instrument - Analytical
![Image representing C8 ProteCol HPLC Capillary Columns](http://www.trajanscimed.com/cdn/shop/products/hplc_capillary_columns_hplc_capillary_column_protecol_dark_blue_sge_image_13e0cabb-18b0-4777-a388-8d2671c7380e.jpg?v=1571276982&width=1024)
C8H x 3 µm Particle Size x 1000 Å Pore Size, 150 mm Length x 150 µm ID, PEEKsil ProteCol HPLC Capillary Column
Collections: All, Analytical, C8 ProteCol HPLC columns, ProteCol HPLC capillary columns, Select by instrument - Analytical
![Image representing C8 ProteCol HPLC Columns](http://www.trajanscimed.com/cdn/shop/products/hplc_columns_reverse_phase_hplc_column_protecol_c18_red_sge_image_4c3c1856-0e99-48ee-a0e5-cfc1857166d6.jpg?v=1571276986&width=1024)
C8H x 3 µm Particle Size x 1000 Å Pore Size, 150 mm Length x 4.6 mm ID, PEEK Coated ProteCol HPLC Column
Collections: All, Analytical, C8 ProteCol HPLC columns, Select by instrument - Analytical
![Image representing C8 ProteCol HPLC Columns](http://www.trajanscimed.com/cdn/shop/products/hplc_columns_reverse_phase_hplc_column_protecol_c18_red_sge_image_f22701bc-2936-4208-a77f-5ed5dc9fb8ed.jpg?v=1571276986&width=1024)
C8H x 3 µm Particle Size x 1000 Å Pore Size, 150 mm Length x 4.6 mm ID, Stainless Steel ProteCol HPLC Column
Collections: All, Analytical, C8 ProteCol HPLC columns, Select by instrument - Analytical
![Image representing C8 ProteCol HPLC Columns](http://www.trajanscimed.com/cdn/shop/products/hplc_columns_reverse_phase_hplc_column_protecol_c18_red_sge_image_c317d41a-1e15-44b9-9988-868f686766c1.jpg?v=1571276986&width=1024)
C8H x 5 µm Particle Size x 120 Å Pore Size, 150 mm Length x 4.6 mm ID, PEEK Coated ProteCol HPLC Column
Collections: All, Analytical, C8 ProteCol HPLC columns, Select by instrument - Analytical
![Image representing C8 ProteCol HPLC Columns](http://www.trajanscimed.com/cdn/shop/products/hplc_columns_reverse_phase_hplc_column_protecol_c18_red_sge_image_741db81b-8535-4d10-9dd9-790e743af49e.jpg?v=1571276986&width=1024)
C8H x 5 µm Particle Size x 120 Å Pore Size, 150 mm Length x 4.6 mm ID, Stainless Steel ProteCol HPLC Column
Collections: All, Analytical, C8 ProteCol HPLC columns, Select by instrument - Analytical
![Image representing C8 ProteCol HPLC Columns](http://www.trajanscimed.com/cdn/shop/products/hplc_columns_reverse_phase_hplc_column_protecol_c18_red_sge_image_4ea03620-b1a9-487b-8368-b4c8546c9487.jpg?v=1571276986&width=1024)
C8H x 5 µm Particle Size x 120 Å Pore Size, 250 mm Length x 4.6 mm ID, PEEK Coated ProteCol HPLC Column
Collections: All, Analytical, C8 ProteCol HPLC columns, Select by instrument - Analytical
![Image representing C8 ProteCol HPLC Columns](http://www.trajanscimed.com/cdn/shop/products/hplc_columns_reverse_phase_hplc_column_protecol_c18_red_sge_image_dc3de426-b6cc-40a1-8f51-775cf942ac94.jpg?v=1571276987&width=1024)
C8Q x 3 µm Particle Size x 300 Å Pore Size, 10 mm Length x 530 µm ID, PEEKsil ProteCol HPLC Guard Column, PK3
Collections: All, Analytical, C8 ProteCol HPLC columns, Select by instrument - Analytical
